| Remote Operating Support : | Machine can be operated remotely using any remote software like Anydesk / Ultraviewer. This is very nice feature that helps for training and trouble shooting. |
| Simultaneous 4 Axis : | Machine can accept 4 axis gcode to run all X, Y Z and A axis all together. This enable use to make carving operation on flat and circular surface. Some special type of pillar can do only with simultaneous 4 Axis capability. |
| Dome Light Indication : | Yellow Light indicates Main Power Supply is Applied. Green Light Indicates Machine Power is On. Red Light indicates Machine is at Emergency Stop mode. |
| Auto Lubrication : | Automatic lubrication systems consist of a central reservoir supplying lubricant through distribution lines to directly slider blocks. |
| Auto Dust Collection : | Automatic dust collection systems efficiently capture and contain dust and debris generated during industrial processes, employing strategically placed hoods, ductwork, a central collector with filtration, and regular maintenance for optimal performance and safety. |
| Auto Stop : | Machine will stop Automatically if any Servo motor and spindle motor overload its rated capacity. This feature will help you to avoided savior mechanical damage because of collision. |
| Auto Origin : | When you start the machine, machine set the X and Z Origin Automatically. If this facility is not there then you must set the origin manually which can never be accurate. |
| Auto Tool zero : | Machine have Sensor for accurate measurement of both turning and carving tool lengths. Software store tool length and update the Y origin automatically. Without Auto tool zero you have to update origin on each wood size. |
| ATC - Auto Tool Change : | Automatic tool change (ATC) in CNC machines automates tool swapping, housed in a tool magazine and selected by the CNC program. During machining, the machine pauses to change tools, retrieving and inserting them using a robotic arm. Optional tool measurement ensures precision, and clamping secures the new tool before resuming operations, streamlining manufacturing and enhancing productivity. |
| Weight : | 1700 KG |
| Power Consumption : | 13KW (3 Phase) |
| Position Accuracy : | 0.05 mm (50 Micron) |
| Max Rapid Speed : | 14000 mm/min |
| Axis Motion Motor : | Servo Motor |
| Bed Type : | T-Slot Aluminium (Vacumme Bed Also Avaialble) |
| ATC Carving Tool Station : | 6 Tool Station (ISO30 - ER32 Collets) |
| Spindle Specification : | Power : 6 kw , Air Cooled 18000 RPM, ISO30 Holder, Er32 Collet |
| Carving Spindle Type : | ATC - Automatic Tool Change |
| Max Material Thickness : | 3 inch (Customisable) |
| Bed Size : | 4x8 Feet (customisable) |
| Operations : | D Profile Cutting and Pocketing, Drilling, 3D Carving, 2.5D Carving(V Carving) |
